| Battery Rated Capacity | 280Ah | |
System Parameters | DC Rated Voltage | 1331.2V |
Maximum Charge/Discharge Rate | 0.5CC/0.5CD | |
| DC Rated Energy | 372.7kWh | |
DC Round Trip Efficiency @ Rated Power | ≥94% | |
| Battery Chemistry | LFP | |
| Fire Suppression | Aerosol + water | |
Cooling Concept of Battery Chamber | Liquid cooling | |
| Codes & Compliance | UL9540/CE/IEC | |
| Weight (Approximate) | 3.5T | |
Enclosure Dimensions (W*H*D） | 1400*2350*1400mm | |
| Enclosure Rating | IP55 | |
Operating Temperature Range | -30℃～+55℃ | |
| Software | Communication Interfaces | RS485、CAN、LAN |
| Communication Protocols | ModBus TCP/ModBus RTU/CAN |
Battery Energy Storage System
Promote the Transformation of the Energy Structure
Ecube L - Liquid Cooling Energy Storage CabinetBack
Technical Advantages
•Flexible Deployment: Modular energy cabinet, flexible expansion, IP55 to meet a variety of outdoor application scenarios.
•Ultra-long Life: High capacity and long battery cycle life, efficient active balancing system, 20 years of system designed life.
•High Level of Safety: Multi-safety design & multi-protection assurance Pre-alarm system, ensure system safety. Eligible for NFPA855, UL9540, UL9540A, GB standards.
•Efficient Management: High-efficiency liquid cooling system, system temperature difference ≤ 3℃.
- Product Performance
